A new process has been developed to remove the polymeric layer formed on
a printed circuit board. A piece of polymeric film was removed from the
polymeric layer with a single shot of infra-red (IR) laser irradiation
of a wavelength which is transparent in the polymer. In order to apply
this process to a laser drill, technical data were obtained about the dependencies
of hole diameter on laser fluence, radiation field, and polymeric layer
thickness. The mechanism of the process has been investigated.
The luminescent spectra measured during the IR laser irradiation significantly
depend on the degree of fluence. When a single IR laser pulse was shot
at a higher fluence of 8.6J/cm2, several intense peaks were observed on the spectrum, but these peaks
disappeared at a low laser fluence of 1.2J/cm2. This suggests that the polymeric film was removed without decomposition
into atomic species.@Therefore, this process differs considerably from
ordinary ablation processes.
Based on these experimental data, this process is considered to remove
the radiated polymer film without decomposing the polymer to the level
of atom or molecule. This new process has the following potential advantages
compared with the conventional laser ablation processes: (1) the piece
of polymeric layer is removed completely by a single shot of IR laser pulse,
and (2) the problems such as debris, delamination and smear which occur
by CO2 or UV laser irradiation are avoided. These are the specific characteristics
of this new process.
|
